Printing Method

Direct Thermal & Thermal Transfer

  Printing Resolution

203 dpi(8 dots/mm)

  Printing Speed

Max. 6 ips

  Printing Length

Max. 100”(2540mm)

  Printing Width

Max. 4.25”(108mm)

  Memory

128MB DRAM, 128MB Flash ROM

  CPU Type

32 bit RISC microprocessor

  Sensors

Reflective sensor x 1 (Movable) & Media Transmissive sensor x 1 (centrally fixed)

  Operation Interface

LED Indicator x 2, Button(Feed) x 1

  Communication Interface

CX-2040 Pro : USB 2.0 device, CX-2140 Pro : Ethernet 10/100 Mbps, USB 2.0 device, RS-232, USB 2.0 host

  Fonts

Internal character sets standard 5 alpha-numeric fonts from 0.049”H ~ 0.23” H (1.25mm ~ 6.0mm) Internal fonts are expandable up to 24x24 4 direction 0° ~ 270° rotation Soft fonts are downloadable Ability to print any Windows True Type font easily. Support scalable font. GB 18030 Standard (Chinese coded character set) support.

  Wireless Security

N/A

  1D Barcodes

UPC-A, UPC-E, JAN/EAN, CODE39, CODE93, CODE128, GS1-128 (UCC/EAN128), CODABAR (NW-7), ITF, Industrial 2of5, MSI, UPCadd-on code, POSTNET, GS1 DataBar Omnidirectional, GS1 DataBar Truncated, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirecional, GS1DataBar Limited, GS1 DataBar Expanded, GS1DataBar Expanded Stacked

  2D Barcodes

QR Code, PDF417 (includingMicroPDF), DataMatrix (ECC200), GS1 DataMatrix, MaxiCode

  Graphics

PPLA: PCX, BMP, IMG, HEX and GDI format files PPLB: PCX, BMP , Binary Raster, and GDI PPLZ: GRF, Hex and GDI

  Emulation

PPLA, PPLB, PPLZ

  Software-label Editing

BarTender® from Seagull Scientific. Argobar Pro support ODBC Database Connection: Excel, CSV, MS Access, MS SQL, Oracle MySQL, dBASE (*.dbf), iLabelPrint+

  Software-utility

Printer Tool, Font Utility

  Driver tools

Windows 10 ,Windows 11,Windows Server 2016 64-bit (x64) editions, LINUX Driver, macOS Driver, Raspberry Pi Driver

  Media Type

Roll-feed, die-cut, continuous, fan-fold, black mark, tags, ticket in thermal paper or plain paper

  Media

Max. width: 4.65” (118mm). Min. width: 0.8” (20mm). Thickness: 0.0024”~0.008” (0.06mm~0.2mm) Max. roll capacity (OD): 5"(127 mm) Core size 1”(25.4mm) Max. roll capacity (OD): 4.5"(114.3 mm) Core size 0.5”(12.7mm) Max. roll capacity (OD): 4.7"(120 mm) Core size 1.5”(38.1mm)

  Ribbon

Ribbon width: 1”~4.33”(25.4mm~110mm), Ribbon length: Max. 300m. Core size ID: 1”(25.4mm), optional: 0.5”(12.7mm), Core width: 2.6”(67mm) Wax, Wax/Resin, Resin (Ribbon wound ink-side out or ink-side in: auto-detect)

  Drop Resistance

N/A

  Printer Dimensions

W 226mm x H 188mm x D 276mm

  Printer Weight

2.1 kgs

  Power Source

Universal Switching Power supply. AC input voltage: 100~240V, 50~60Hz. DC Output: 24V, 2.4A

  Battery

N/A

  Operation Environment

Operation Temperature: 40°F~100°F (4°C~38°C), 0% ~ 90% non-condensing Storage Temperature: -4°F~122°F (-20°C~50°C)

  Real Time Clock

N/A

  Standard Item

N/A

  Optional Items

Guillotine Cutter, Rotary Cutter, Peeler, External media stand

  Agency Listing

CE, FCC, cULus, RoHS, BIS, BSMI, KC

  Attention

*Argox reserves the right to enhance and modify the specification without prior notice. Please check Argox sales representative for most updated specifications.
